Portable Leeb Hardness Tester (MH180)

R 14,780.00

Tax includedShipping calculated at checkout

Mitech SKU: MH-180

Available Now!

Add R 2,000.00 more for FREE shipping!

Shipping
Ships in 1-3 business days

Warranty
1 year standard warranty

Product Overview

The Mitech MH180 Portable Leeb Hardness Tester is a lightweight, compact, and cost-effective tool for on-site hardness testing of a wide range of metallic materials. Based on the Leeb hardness principle, it provides fast and reliable results with automatic conversion between hardness scales including Leeb (HL), Brinell (HB), Rockwell (HRC/HRB), and Vickers (HV).

Its high-contrast LCD display, stable performance, and durable build make the MH180 an excellent choice for regular industrial use, failure analysis, and production quality control — offering great value without compromising reliability.


Key Features

  • Hardness Conversion: Supports HL, HB, HRB, HRC, and HV

  • Compact & Lightweight: Designed for easy transport and field testing

  • High-Contrast Segment LCD: For clear readability in any light

  • Quick Impact Testing: Based on rebound velocity measurement

  • Reliable Performance: Stable output with repeatable accuracy

  • Affordable & Practical: Ideal for general-purpose industrial hardness testing


Applications

  • Die cavities and precision molds

  • Steam generators and pressure vessels

  • Bearings, shafts, and engine parts

  • On-site testing of permanently assembled components

  • Large-scale metallic workpieces

  • Inventory material identification and failure analysis

Specifications

Working Voltage 3V(two AA size, alkaline batteries)
Power supply Two ordinary AA batterie
Measuring range (170~960)HLD
Impact direction vertically downward, oblique, horizontal, oblique, vertical upward, automatically identify
Error D,±6 HLD
Repeatability D,6 HLD
Material Steel and cast steel, Cold work tool steel, Stainless steel, Grey cast iron, Nodular cast iron, Cast alu
Hardness Scale HL、HB、HRB、HRC、HRA、HV、HS
Impact energy D----11mJ
Impact weight D----5.5g/7.2g
Impact ball hardness D----1600HV
Impact ball diameter D----3mm
Impact ball material D----Tungsten carbide
Sample surface roughness D----1.6μm;C----0.4μm
Min depth of harness layer D----≥0.8mm;C----≥0.2mm
Display High-contrast Segment LCD
Storage 100 measurement series.(Relative to average times 32~1)
Calibration Single-point calibration
Data printing Thermal printing on site
Power consumption Low-power design
Standby period About 100h(without backlight)
Communication port USB1.1
Working language English
Shell material ABS plastic
Dimensions 150mm×74mm×32 mm
Weight 4.0KG
PC software None

PDF Specification Sheet - Download Here
