Anemometer Type C

Product Description

This instrument is widely used in various industries for data collection purposes. It finds application in the boiler and refrigeration industry, ventilation ducts, environment monitoring, navigation measurements, weather forecasting, collection of weather data for outdoor work, and fire departments.

Features

• The measurement unit can be selected according to specific requirements.
• Maximum value data hold function.
• DATA HOLD function for storing up to 24 groups of data.
• Low-friction ball-bearing design allows for free movement of the vane.
• Separate type design for convenient measurement.
• Wide range of applications: can be used to check air conditioning and heating systems, measure air velocities, wind speeds, temperature, etc.
• Automatic power off with user-settable time duration (0-9 minutes).
• Offers USB data output and RS-232 data output for connection to a computer.
• Provides the option for Bluetooth™ data output.

General Specifications

• Measurement unit:
  • Air Flow: CMM(m³/min) CFM(ft³/min)
  • Beaufort scale: Force
  • Direction: ° from the North direction
  • Wave Height: m
  • Temperature: ? & ?
• Data hold: Maximum Value
• Data memorized: 24 groups
• Sampling rate: Approximately 1 reading per second
• Sensors:
  • Air velocity/flow sensor: 3-cup probe
  • Direction probe: Low friction probe
  • Temperature sensor: Precision thermistor
• Automatic Power off: Set by users between 0-9 minutes
• Operating Temperature: -10? to 60? (14? to 140?)
• Operating Humidity: Maximum 80% RH
• Power Supply: 4x1.5AAA size batteries
• Dimensions:
  • Main Unit: 140x70x30mm
  • 3-cup probe: 65x65x115mm
  • Direction probe: 86x69x115mm
• Weight: 310g (Including probe)

Range Specifications

Air Velocity:

• Range: 0.4-45.0 m/s
• Resolution: 0.1 m/s
• Accuracy: ±(2%+0.1 m/s)
