Sinowon ST Series Salt Water Spray Test Chamber

Sinowon ST Series Salt Water Spray Test Chamber

Models: ST Series
Warranty: 12 months
Delivery Time: 15-30 days
Certificate: CE

Product Characteristics:

Durable Construction: Made of imported PP rigid plastic plates, ensuring a solid and robust structure resistant to acid, alkali, high temperatures, corrosion, and aging.

Precision Nozzle: Utilizes plastic precision nozzles and conical spray devices to ensure even and quick fog distribution, with a long service life and no crystallization.

LCD Touch Screen: Equipped with an LCD touch screen that can be connected to a computer for remote monitoring and operation, supporting language switching between Chinese and English.

USB Interface: Features a USB interface for downloading curves and historical data via a U disk, eliminating the need for a separate recorder (optional).

Internal Control: Spray time can be controlled internally without requiring additional time relays.

Regulated Flow: The flow rate of salt water and the pressure of compressed air are regulated by flow meters and high-pressure valves to ensure uniform salt spray deposition.

Manual Water Addition System: Ensures automatic water replenishment when the water level is insufficient, guaranteeing uninterrupted testing.

Product Application:

Suitable for conducting salt spray tests to assess the corrosion resistance of various materials, including surface treatments such as coating, electroplating, anodizing, spraying, and rust-proof oil.
Specifications:

Model SST-90-BS SST-120-NS SST-160-NS SST-200-NS
Code# 221-121T 221-131T 221-141T 221-151T
Test Conditions NSS (neutral), ASS (acidic), CASS (copper accelerated)
Interior Dimensions (WDH)mm 900600500 1200850500 1600850550 2000950600
Exterior Dimensions (WDH)mm 14609101280 190011501500 230011501550 270013501600
Workroom Volume (L) 270 480 800 1440
Capacity of Salt Water Tank (L) 25 90 90 120
Test Temperature NSS ACSS: 35°C±1°C, CASS: 50°C±1°C
Temperature of Saturated Drum NSS ACSS: 47°C±1°C, CASS: 63°C±1°C
Heating Method Thermal radiation heating
Temperature of Saline Water 35°C±1°C / 50°C±1°C
Test Fluid NSS: purified water + sodium chloride (PH6.5-7.2), CASS: purified water + sodium chloride + copper chloride (PH3.0-3.2)
Compressed Air Pressure 2kgf/cm² 2kgf/cm² 6kgf/cm² 6kgf/cm²
Power Supply AC 220V, 1Φ, 50HZ
Note: Actual product dimensions may vary.
