Overview
This AGH6600 is a custom, supplied-to-order pumped dual-gas detector for hydrogen sulphide and sulphur dioxide. It brings H2S and SO2 measurement together with an integrated sampling pump, an LCD display and audible, visual and vibration alarms. Only the two specified gas sensors are included in this configuration.
Key features
- H2S and SO2 monitoring in one portable instrument.
- Built-in sampling pump for suitable probe and hose arrangements.
- LCD concentration display and stored measurement data.
- Rechargeable design with USB Type-C charging.
- Protective PC/TPU housing with manufacturer-stated IP66 protection.
Applications and selection
For industrial inspections and process-area sampling where the monitoring requirement identifies both H2S and SO2. Choose this version when a built-in pump is required; the corresponding AGH6200 dual-gas version uses diffusion sampling. This instrument does not measure oxygen, CO, CO2 or combustible gas and is not a complete substitute for a separately specified four- or six-gas configuration.
Specifications
| Model | AGH6600 |
|---|---|
| Gas configuration | H2S / SO2; two gases |
| Hydrogen sulphide (H2S) | 0–100 ppm |
| Sulphur dioxide (SO2) | 0–20 ppm |
| Sampling | Built-in pump |
| Display / alarms | LCD / audible, LED and vibration |
| Enclosure | PC/TPU; manufacturer-stated IP66 |
| Dimensions | 177 × 76.5 × 40 mm (H × W × D) |
| Operating temperature | −20 to +60 °C; selected sensor restrictions also apply |
| Charging | USB Type-C |
Confirm the final sensor schedule and ranges on the order documentation.
Standards and compliance
Match the approval marking and certificate scope to the exact supplied model and gas configuration before hazardous-area use. Follow the manual for calibration, alarms and sampling. Confirm sampling-line suitability and allow for the specified sample transit and instrument response times.
Included and optional accessories
One AGH6600 with built-in pump and H2S / SO2 sensors. Confirm the charger, sampling probe, hose and filter packing list when ordering. Calibration cap, calibration gas, regulator and accredited calibration should be specified separately and are not included unless expressly quoted.
Compare the gas detection range
This page: H2S / SO2, AGH6600 with built-in pump. Each listing is a separate instrument configuration; only its stated gases are measured.
| Instrument / gases | Model | Sampling |
|---|---|---|
| Oxygen (O2) | AGH5200 | Diffusion |
| Carbon monoxide (CO) | AGH5200 | Diffusion |
| Hydrogen sulphide (H2S) | AGH5200 | Diffusion |
| Ammonia (NH3) | AGH5200 | Diffusion |
| Sulphur dioxide (SO2) | AGH5200 | Diffusion |
| Nitrogen dioxide (NO2) | AGH5200 | Diffusion |
| Four-gas: LEL / O2 / CO / H2S | AGH6200 | Diffusion |
| Four-gas: CO / O2 / NH3 / NO2 | AGH6200 | Diffusion |
| Dual-gas: H2S / SO2 | AGH6200 | Diffusion |
| Six-gas: LEL / O2 / CO / H2S / SO2 / CO2 | AGH6600 | Built-in pump |
| Four-gas: CO / O2 / NH3 / NO2 | AGH6600 | Built-in pump |
| Dual-gas: H2S / SO2 | AGH6600 | Built-in pump |
| Gas sampling pump | AGH1000B | External pump; detector required |
This comparison is not a universal compatibility list. Confirm sensor ranges, sampling accessories and certificate scope for the application. Browse gas detection and environmental safety equipment.
Datasheet
The manufacturer document covers the AGH6600 platform. This listing includes only the H2S / SO2 configuration; read the document with the final quotation.
Download the AGH6600 manufacturer datasheet (PDF)
Applications
- Confined-space entry and pre-entry testing
- Oil, gas, chemical and wastewater facilities
- Plant maintenance and shutdown work
- Occupational safety and emergency response
