NDE-1546 NDT Standard Flawed Specimens Kit – UT, MT, PT, RT & VT

The NDE-1546 NDT Standard Flawed Specimens Kit is a set of carbon steel test specimens containing intentionally placed discontinuities for NDT demonstration and training across multiple inspection methods.

The complete kit contains five specimens – three plates, one pipe and one tee – with 15 randomly placed flaws. The specimens provide practical samples for demonstrating Ultrasonic Testing (UT), Magnetic Particle Testing (MT), Liquid Penetrant Testing (PT), Radiographic Testing (RT) and Visual Testing (VT).

NDT verification reports are supplied for documentation and reference.

Key Features

• Complete 5-piece NDT flawed specimen kit

• Suitable for UT, MT, PT, RT and VT demonstrations

• Carbon steel construction

• 15 randomly positioned discontinuities

• Approximately 2–3 flaws per specimen

• Includes plate, pipe and tee configurations

• NDT verification reports supplied

• Suitable for NDT training and demonstration

Kit Contents

Total: 5 specimens with 15 flaws

• MT/PT: 1 × Tee – 0.25" T × 4" × 8" × 4"

• VT: 1 × Plate – 0.25" T × 4" × 8"

• RT: 1 × Plate – 0.625" T × 4" × 8"

• UT: 1 × Pipe – 4" Sch 80 (0.337" wall) × 8"

• UT: 1 × Plate – 0.625" T × 4" × 8"

Technical Specifications

NDT Methods Covered

Ultrasonic Testing (UT)
Pipe and plate specimens for ultrasonic inspection demonstration.

Magnetic Particle Testing (MT) & Penetrant Testing (PT)
Tee specimen for demonstrating surface flaw detection techniques.

Radiographic Testing (RT)
Carbon steel plate specimen for radiographic inspection demonstration.

Visual Testing (VT)
Plate specimen for visual inspection and flaw identification.

Typical Applications

• NDT training centres

• Technician training

• NDT method demonstrations

• Practical inspection exercises

• Training laboratories

• Technical colleges and universities

• In-house NDT training programmes

Documentation

Supplied with NDT Verification Reports for the flawed specimens.

Downloads

Data Sheet Link
