Halogen Moisture Analyzer 110g TME Series (Entry)

R 11,700.00

Tax includedShipping calculated at checkout

Tomlin Instruments SKU: TM-TME110

Model Selection: TME110
Calibration: Without Calibration Certificate

Shipping
Ships in 5-10 business days

Warranty
1 year standard warranty

Description

The TOMLIN INSTRUMENTS TME Series Halogen Moisture Analyzer is an entry-level solution designed for reliable and efficient moisture content determination. It is ideal for routine laboratory and industrial applications where simple operation and consistent results are required.

With a compact design and intuitive interface, the TME Series delivers stable performance and fast drying using halogen heating technology. It offers multiple drying modes and flexible operation, making it a cost-effective choice for basic moisture analysis across a wide range of materials.


Features

  • 5-inch full-color display for easy operation
  • Halogen heating system for fast and uniform drying
  • Standard, fast, and gentle drying modes
  • Auto, manual, and timed shutdown options
  • Real-time test curve display
  • Adjustable temperature and time settings
  • Silent rapid-cooling fan system
  • History record and clock function
  • Compact and user-friendly design

Specifications


Product specifications

                                        TME Series

Name

TME110

TME105

TME101

Model

TME110

TME105

TME101

Capacity

110 g

110 g

110 g

Readability

0.01 g

0.005 g

0.001 g

Sensor

 Load Cell

 HBM

Pan Size

 Φ96mm(20pcs)

Display

5 inch touch screen

Operate.Temp

5℃-35℃

Heating Source

 Halogen lamp

Temp.Sensor

PT-100-2

Temp.Range

40℃-160℃

Temp.Setting

1℃

Moisture.Range

90.00%-10.00%

95.00%-5.00%

100.00%-0.00%

Moisture Readability

0.1%

0.05%

0.01%

Testing Range

90.00%-10.00%

95.00%-5.00%

100.00%-0.00%

DRY% Readability

0.1%

0.05%

0.01%

Storage

20 Groups

Analysis Curve

Real time dynamic curve

Testing Height

30mm

LANGUAGE

  EN/CN

Power supplier

220V 50Hz  / 110V 60Hz

Dimension

336X214X166mm

Packing Size

415*310*255mm

G.Weight/N.Weight

4.0kg/3.5kg

Industries Used In

  • Food and beverage processing
  • Agriculture and grain testing
  • Chemical materials testing
  • Plastics and polymer production
  • Quality control laboratories

Downloads

Product Data Sheet Link
