The CEM DT-6605 is a professional 5 kV high-voltage insulation resistance tester for motors, generators, cables, switchgear and other industrial electrical assets. Its wide test-voltage range and diagnostic functions make it suited to commissioning and preventative maintenance.
Key Features
- Insulation test voltages: 500 V, 1000 V, 2500 V and 5000 V
- Insulation resistance measurement up to 60 GΩ
- Polarisation Index (PI) measurement
- Automatic ranging and timed testing
- Output-voltage and discharge-voltage indication
- Automatic discharge after insulation testing
- Voltage-output warning function
- 6000-count backlit digital display with bargraph
- AC/DC voltage measurement and continuity function
- IEC 61010-1 CAT IV 600 V
Applications
- Industrial motors and generators
- Power cables and switchgear
- Electrical plant maintenance
- High-voltage insulation condition checks
Model: CEM DT-6605
Specifications
| Specification | Details |
|---|---|
| Insulation test voltages | 500 V / 1000 V / 2500 V / 5000 V |
| Insulation resistance | Up to 60 GΩ |
| Accuracy | ±5% rdg ±3 dgt; ±20% above 6 GΩ |
| Short-circuit current | Approx. 1.3 mA |
| Rated test current | Approx. 1 mA to 1.2 mA at specified load |
| AC/DC voltage | 0 to 600 V |
| Resistance / continuity | 0 to 6000 Ω; buzzer at approx. 50 Ω |
| Display | 6000 counts, backlit |
| Functions | PI, auto-ranging, timer, auto-discharge |
| Safety rating | IEC 61010-1, CAT IV 600 V |
