Overview
The FST700-101 and FST700-102 are hydrostatic submersible level transmitters for continuous liquid-level measurement in tanks, reservoirs, boreholes and process applications.
Available models
- FST700-101: standard submersible level transmitter with a 0–5 mH₂O, 4–20 mA output, 9–30 V DC supply, ±0.5% FS accuracy, 28 mm probe diameter and 316L construction.
- FST700-102: anti-corrosion submersible level transmitter with a 0–3 mH₂O with 4 m cable, 4–20 mA output, 9–30 V DC supply, ±0.5% FS accuracy, 28 mm probe diameter and 316L construction.
Specifications
| Model | FST700-101 | FST700-102 |
|---|---|---|
| Measuring range | 0–5 mH₂O | 0–3 mH₂O |
| Output | 4–20 mA | 4–20 mA |
| Supply | 9–30 V DC | 9–30 V DC |
| Accuracy | ±0.5% FS | ±0.5% FS |
| Probe diameter | 28 mm | 28 mm |
| Probe material | 316L | 316L |
| Cable | — | 4 m |
| Protection | IP68 | IP68 |
Applications
- Water tanks and reservoirs
- Boreholes and wells
- Wastewater systems
- Industrial tanks and process vessels
Protection and documentation
Both models are IP68 and CE marked.
