Overview
The FST500-602A is a colour-display paperless recorder for centralised monitoring and recording of industrial process signals.
Specifications
| Display | 7-inch colour LCD |
|---|---|
| Input channels | 3 |
| Accuracy | ±0.25% FS |
| Outer dimensions | 194 × 162 × 147 mm |
| Panel cut-out | 137 × 137 mm |
| Power supply | 220 V AC or 24 V DC |
Applications
- Temperature and process recording
- Pressure, level and environmental monitoring systems
- Laboratory and test-system recording
- Industrial monitoring panels
